| REF. | АРТИКУЛ | ОПИСАНИЕ | ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
|---|---|---|---|
| 1 | 5.050-061.0 | Frame | |
| 1 | 6.472-107.0 | Screw ventilation | |
| 2 | 6.631-469.0 | Protective cover (Y30600101) | |
| 2 | 6.472-106.0 | O-Ring seal 5,0 X 1,8 | |
| 3 | 6.631-758.0 | Rocker switch | |
| 3 | 6.472-111.0 | O-Ring seal 32,0 X 1,6 | |
| 4 | 5.321-449.0 | HANDLE SWITCHES | |
| 4 | 6.472-112.0 | O-Ring seal 10,0 x 2,4 NBR 70 | |
| 5 | 6.313-014.0 | Spring element | |
| 5 | 6.472-113.0 | Filter cartridge | |
| 6 | 6.362-078.0 | O-Ring seal 13,3x2,4 | |
| 6 | 6.472-123.0 | Filter housing complete | |
| 7 | 6.303-155.0 | Screw 5x16 | |
| 7 | 6.472-122.0 | Protecting cap | |
| 8 | 6.472-109.0 | Housing spring | |
| 10 | 5.380-430.0 | Табличка FT 500 | |
| 10 | 6.472-108.0 | Pin | |
| 12 | 6.472-128.0 | Diaphragm | |
| 14 | 6.472-340.0 | Knurled nut |
