| REF. | АРТИКУЛ | ОПИСАНИЕ | ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
|---|---|---|---|
| 0 | 4.321-088.0 | Steam hose complete grey RAL 7004 | |
| 0 | 4.321-114.0 | Steam hose complete black RAL 9005 | |
| 1 | 5.321-596.0 | Handhold few black | |
| 1 | 5.321-510.0 | Handhold few grey RAL 7004 | |
| 2 | 5.367-024.0 | Diaphragm | |
| 3 | 5.367-025.0 | Ring diaphragm | |
| 4 | 5.363-366.0 | Joint ring 21 | |
| 4 | 5.394-374.0 | Protection part | |
| 5 | 6.389-862.0 | Hose silicon DN4 | |
| 5 | 4.440-603.0 | Hose complete black nur fuer Ersatz | |
| 6 | 6.390-287.0 | Hose D 3 x 1,35 | |
| 6 | 6.389-799.0 | Hose D 3 x 1,35 | |
| 6 | 6.631-802.0 | Micro switch | |
| 7 | 6.906-024.0 | Hose sheathed | |
| 7 | 5.324-029.0 | Pushbutton | |
| 8 | 6.390-162.0 | Hose clip | |
| 8 | 5.332-168.0 | Pressure spring | |
| 9 | 6.414-439.0 | Filter fine dust | |
| 9 | 4.580-368.0 | Valve complete | |
| 10 | 5.322-010.0 | Hand wheel | |
| 11 | 5.031-064.0 | Slider | |
| 12 | 5.031-125.0 | Notch | |
| 13 | 6.362-922.0 | O-Ring seal 8,73x1,78 | |
| 14 | 5.037-102.0 | Hook | |
| 14 | 5.037-155.0 | Hook yellow | |
| 15 | 4.471-001.0 | Coupling element complete only for repla | |
| 18 | 6.303-058.0 | Oval head screw 2,9X 13-ST-VERZ | |
| 19 | 5.031-060.0 | Plug shells | |
| 19 | 5.032-780.0 | Plug shells | |
| 20 | 6.362-923.0 | O-Ring seal 6,75X 1,78 | |
| 21 | 5.409-515.0 | Nipple for steam hose | |
| 22 | 6.641-402.0 | Wire protecting sleeve | |
| 22 | 6.647-513.0 | Strain relief | |
| 23 | 6.647-881.0 | Cable gland | |
| 23 | 6.646-325.0 | Plug element | |
| 24 | 6.362-927.0 | O-Ring seal 21,89X 2,62 -EPDM | |
| 25 | 6.280-175.0 | Heat master paste | |
| 25 | 6.389-884.0 | Hose clip 11,8 | |
| 26 | 7.303-095.0 | Screw 4x 12-ST-10.9-R2R (IN6RD) | |
| 26 | 5.031-123.0 | Strain relief | |
| 27 | 5.363-347.0 | Seal | |
| 27 | 5.332-373.0 | Helical spring | |
| 28 | 5.364-174.0 | Flat gasket |
