| REF. | АРТИКУЛ | ОПИСАНИЕ | ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
|---|---|---|---|
| 1 | 6.303-193.0 | Cylinder head screw M 6X 12-8.8-R2R | |
| 1 | 6.412-043.0 | Spare part set C | |
| 2 | 5.332-066.0 | Helical spring | |
| 3 | 7.401-928.0 | Sphere 8 G300 -1.4301 DIN 5401 | |
| 4 | 6.362-481.0 | O-Ring seal 14,0 x 2,0 NBR 80 | |
| 5 | 5.581-160.0 | Valve seat | |
| 6 | 6.362-799.0 | O-Ring seal 18,0 X 1,0 | |
| 7 | 6.362-079.0 | O-Ring seal 18,0 X 2,5 | |
| 8 | 5.305-193.0 | Shaped screw | |
| 9 | 6.412-049.0 | Excess-current -FA. SUTTNER | |
| 10 | 6.421-214.0 | Pressure gauge 0-300 BAR | |
| 11 | 7.382-301.0 | """Screw plug R 1/4""""-St-A2E DIN 906 """ | |
| 12 | 7.382-300.0 | Screw plug M10x1-St-A2E DIN 906 | |
| 13 | 7.311-439.0 | Hexagon nut M 8x1,0-6-A2E ISO 10512 | |
| 14 | 6.412-045.0 | Hand wheel cap | |
| 15 | 6.385-786.0 | Reducing nipple | |
| 18 | 6.414-666.0 | Filter cartridge only for replacement | |
| 21 | 5.310-076.0 | Nut | |
| 23 | 6.414-688.0 | Filter cup | |
| 25 | 6.385-881.0 | Union nut |
