| REF. | АРТИКУЛ | ОПИСАНИЕ | ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
|---|---|---|---|
| 0 | 4.623-692.0 | Motor complete only for replacement | |
| 0 | 4.623-683.0 | Motor complete | |
| 0 | 4.623-868.0 | Motor complete only for replacement | |
| 0 | 4.623-866.0 | Motor complete only for replacement | |
| 0 | 4.623-699.0 | Motor complete only for replacement | |
| 0 | 4.623-675.0 | Motor complete | |
| 1 | 5.069-121.0 | Корпус | |
| 1 | 5.070-639.0 | Tank oil | |
| 2 | 6.304-099.0 | Saucer-head screw M 6x 18-4.8-R2R | |
| 2 | 5.063-389.0 | Крышка | |
| 2 | 5.063-195.0 | Cover | |
| 3 | 6.310-053.0 | Putting nut | |
| 3 | 6.303-153.0 | Screw M5x15-ST-R2R (IN6RD) | |
| 4 | 5.050-206.0 | Frame front part | |
| 4 | 5.094-148.0 | Bearing cover B | |
| 4 | 5.064-197.0 | Bearing cover B | |
| 5 | 5.032-554.0 | Guide | |
| 6 | 5.321-721.0 | Hand grip | |
| 7 | 5.050-207.0 | Frame rear panel | |
| 8 | 6.315-086.0 | Rivet | |
| 9 | 5.032-556.0 | Covering cap | |
| 10 | 2.885-007.0 | Spare part set Griff | |
| 11 | 4.063-778.0 | Proportioning valve chemistry |
