Karcher (Керхер) Мотор (0.111-002.0)

Не нашли подходящую запчасть? Позвоните +7 (843) 503-04-85

REF.	АРТИКУЛ	ОПИСАНИЕ
0	4.623-815.0	Motor complete
0	4.624-095.0	Motor complete only for replacement
0	4.623-615.0	Motor complete
0	4.624-091.0	Motor complete only for replacement
0	4.624-093.0	Motor complete only for replacement
0	4.624-012.0	Motor complete only for replacement
0	4.623-618.0	Motor complete
1	5.070-639.0	Tank oil
2	5.063-389.0	Крышка
3	6.303-153.0	Screw M5x15-ST-R2R (IN6RD)
4	5.094-148.0	Bearing cover B
4	5.094-127.0	Bearing cover B
5	5.600-060.0	Blower wheel
6	5.692-081.0	Air circulation
7	6.303-320.0	Screw M 5x 20-St-R2R
8	6.362-161.0	O-Ring seal 19,3 X 2,4
9	7.367-001.0	Radial shaft seal ring A24x37x7 -NBR DI
10	6.401-427.0	Angular contact ball bearing
10	6.401-437.0	Ball bearing
11	5.802-288.0	Mounting part
12	6.401-289.0	Wobble plate
12	6.401-395.0	Wobble plate
13	7.303-108.0	Screw 5x20 -10.9-R2R (In6Rd)
15	9.086-169.0	Болт с шайбой M8x16
17	6.288-050.0	Engine oil 1L
18	5.767-005.0	Rubber buffer
19	7.401-128.0	Ball bearing 6202-2RS -W?lzl.St DIN 625
20	5.116-144.0	Washer
