Karcher (Керхер) Манометрический выключатель (0.141-215.0)
Не нашли подходящую запчасть? Позвоните +7 (843) 503-04-85
| REF. |
АРТИКУЛ |
ОПИСАНИЕ |
ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
| 0 |
4.749-141.0 |
Safety system |
|
| 1 |
5.060-478.0 |
Housing |
|
| 1 |
5.321-577.0 |
Handle |
|
| 2 |
6.363-037.0 |
O-Ring seal complete 1ST.-R. |
|
| 2 |
5.115-798.0 |
Washer |
|
| 3 |
4.553-025.0 |
Piston |
|
| 3 |
2.882-574.0 |
Conversion kit thermostat |
|
| 4 |
5.115-147.0 |
Washer |
|
| 4 |
4.651-026.0 |
Pilot lamp only for replacement |
|
| 5 |
7.303-106.0 |
Screw 4x12 -10.9-R2R (IN6RD) |
|
| 6 |
6.641-270.0 |
Plug |
|
| 7 |
5.107-192.0 |
Bar |
|
| 7 |
6.303-317.0 |
Screw M4x10-St-A2G |
|
| 8 |
5.332-070.0 |
Helical spring |
|
| 8 |
7.311-001.0 |
Hexagon nut M4 -8-A2E ISO 4032 |
|
| 9 |
5.332-069.0 |
Helical spring |
|
| 9 |
4.633-058.0 |
Pulse generator only for replacement |
|
| 10 |
5.112-556.0 |
Bush |
|
| 10 |
5.801-146.0 |
Mounting plate |
|
| 11 |
6.362-169.0 |
O-Ring seal 12,0 X 2,0 |
|
| 11 |
6.643-249.0 |
Strip terminal |
|
| 12 |
5.553-265.0 |
Piston |
|
| 12 |
4.622-018.0 |
Control transformer -nur f?r Ersatz- |
|
| 12 |
6.622-241.0 |
Control transformer 400V |
|
| 13 |
5.332-293.0 |
Helical spring |
|
| 13 |
4.828-007.0 |
Anti-interference filter complete |
|
| 14 |
5.316-278.0 |
Bolt spring |
|
| 14 |
6.647-250.0 |
Cable with rubber bushing |
|
| 15 |
5.060-414.0 |
Housing |
|
| 15 |
6.343-170.0 |
Retaining clip |
|
| 16 |
7.311-002.0 |
Hexagon nut M5 -8-A2E ISO 4032 |
|
| 16 |
5.037-080.0 |
Hook |
|
| 16 |
6.631-190.0 |
Motor protecting switch |
|
| 17 |
7.307-017.0 |
Threaded pin M5x40 -St-45H-A2E ISO 4026 |
|
| 17 |
5.042-618.0 |
Holder |
|
| 17 |
6.630-049.0 |
Cap |
|
| 18 |
5.304-070.0 |
Hexagonal head screw |
|
| 18 |
4.744-115.0 |
Switch safety system |
|
| 18 |
5.481-257.0 |
Lever |
|
| 19 |
7.401-931.0 |
Sphere 5 Kl3 -1.4401 DIN 5401 |
|
| 19 |
5.042-728.0 |
Holder |
|
| 19 |
5.802-261.0 |
Mounting part |
|
| 20 |
5.582-121.0 |
Valve disc |
|
| 20 |
5.316-284.0 |
Bolt |
|
| 20 |
7.312-264.0 |
Washer 5-100HV-A3E ISO 7094 |
|
| 21 |
5.404-082.0 |
Hollow screw |
|
| 21 |
7.303-117.0 |
Screw 4x20 -A2-70 (In6Rd) |
|
| 21 |
6.632-310.0 |
Contactor LC1-K0910 B7SV84 |
|
| 21 |
6.632-356.0 |
Contactor LC1-D18 B7 |
|
| 22 |
5.332-444.0 |
Helical spring |
|
| 22 |
4.622-033.0 |
Ignition transformer only for replacemen |
|
| 22 |
6.622-167.0 |
Ignition transformer 230V |
|
| 23 |
5.584-114.0 |
Valve pin |
|
| 24 |
5.311-204.0 |
Hexagon nut M22x1,5 |
|
| 24 |
5.030-954.0 |
Clamping part |
|
| 25 |
4.553-198.0 |
Piston complete only for replacement |
|
| 25 |
6.646-266.0 |
Coupler plug |
|
| 26 |
6.362-468.0 |
O-Ring seal complete 1ST.-R. |
|
| 26 |
6.651-316.0 |
Lens housing red |
|
| 27 |
4.580-731.0 |
Safety valve only for replacement |
|
| 27 |
6.651-421.0 |
Lens housing green |
|
| 28 |
6.651-604.0 |
Pilot lamp |
|
| 29 |
5.583-146.0 |
Valve screw |
|
| 30 |
6.363-003.0 |
O-Ring seal 13,0 X 2,0-NBR 90 |
|
| 30 |
6.643-151.0 |
Strip terminal one-pole 16mm? |
|
| 31 |
6.362-381.0 |
O-Ring seal 13x2 - NBR 70 |
|
| 32 |
2.884-512.0 |
Valve (3 Stueck) |
|
| 33 |
5.583-130.0 |
Valve screw |
|
| 34 |
6.362-169.0 |
O-Ring seal 12,0 X 2,0 |
|
| 35 |
5.332-414.0 |
Helical spring |
|
| 36 |
5.584-060.0 |
Valve pin |
|
| 37 |
4.582-019.0 |
Valve disc complete |
|
| 38 |
4.580-376.0 |
Ventilating valve |
|
| 38 |
4.686-018.0 |
Temperature limiter only for replacement |
|
| 39 |
6.388-216.0 |
Hose DN 5 |
|
| 39 |
7.306-056.0 |
Screw M4x8 -8.8-R2R (In6Rd) |
|
| 41 |
6.362-077.0 |
O-Ring seal 10 x 2,2 NBR 70 |
|
| 42 |
4.580-349.0 |
Valve complete chemistry |
|
| 44 |
5.443-455.0 |
Hose stem |
|
| 45 |
7.306-106.0 |
Cylinder head screw M8x70 -8.8-A2E ISO4 |
|
| 46 |
4.550-459.0 |
Cylinder head complete only for replacem |
|
| 46 |
4.550-924.0 |
Cylinder head only for replacement |
|
| 47 |
5.110-608.0 |
Sleeve |
|
| 49 |
6.362-547.0 |
O-Ring seal 20,0x1,5-NBR 70 |
|
| 50 |
7.306-043.0 |
Cylinder head screw M8x30 -8.8-A2E ISO |
|
| 51 |
5.587-192.0 |
Valve housing |
|
| 52 |
5.110-797.0 |
Sleeve |
|
| 53 |
4.580-729.0 |
Safety valve kpl. Ersatz |
|
| 54 |
5.321-579.0 |
Handle |
|
| 55 |
6.362-151.0 |
O-Ring d. 10 x 2 NBR 70 |
|
