| REF. | АРТИКУЛ | ОПИСАНИЕ | ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
|---|---|---|---|
| 1 | 7.309-019.0 | Hexagonal head screw M 5x14-8.8-A2E TORX | |
| 1 | 4.553-124.0 | Piston complete | |
| 2 | 5.060-326.0 | Housing | |
| 3 | 5.004-228.0 | Strap | |
| 3 | 6.362-613.0 | O-Ring seal 101,27X 2,62-NBR 70 | |
| 4 | 2.883-083.0 | Spare part set | |
| 4 | 5.030-602.0 | Moulded part | |
| 5 | 5.332-139.0 | Helical spring | |
| 6 | 7.303-039.0 | Screw M5x16 -St-A2R (In6Rd) | |
| 6 | 7.306-023.0 | Cylinder head screw M6x25 -8.8-A2E ISO4 | |
| 7 | 5.668-001.0 | Spark holder | |
| 7 | 6.365-334.0 | Grooved ring 18X26X6/8 | |
| 8 | 7.311-037.0 | Hexagon nut M 5-CU2 ISO 4032 | |
| 8 | 5.115-432.0 | Washer | |
| 9 | 5.667-042.0 | Nozzle holder | |
| 9 | 6.365-332.0 | Compact seal 18x28x5,8 | |
| 10 | 6.362-635.0 | O-Ring seal 50,0x4,0-NBR 70 | |
| 10 | 6.415-565.0 | Nozzle | |
| 11 | 5.365-147.0 | Profile gasket | |
| 11 | 7.306-443.0 | Винт с цилиндрической головкой М4х12 | |
| 12 | 5.071-038.0 | Tank chemistry | |
| 12 | 4.654-133.0 | Cover D.K. | |
| 13 | 6.414-028.0 | Filter | |
| 14 | 6.388-559.0 | Hose clip | |
| 15 | 6.388-225.0 | Hose DN 7 | |
| 15 | 6.278-018.0 | Glass pane | |
| 17 | 6.343-165.0 | Serrated ring | |
| 38 | 4.663-122.0 | Burner cage | |
| 39 | 5.664-179.0 | Burner part | |
| 40 | 7.312-002.0 | Washer 5-200HV-A3E ISO 7090 | |
| 42 | 7.303-078.0 | Sheet metal screw ST4,8X19-ST-A2R (KOMBI | |
| 46 | 7.312-172.0 | Toothed lock washer A5,3-FSt-A3E DIN 67 |
