| REF. | АРТИКУЛ | ОПИСАНИЕ | ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
|---|---|---|---|
| 1 | 7.309-019.0 | Hexagonal head screw M 5x14-8.8-A2E TORX | |
| 3 | 5.004-228.0 | Strap | |
| 4 | 6.472-112.0 | O-Ring seal 10,0 x 2,4 NBR 70 | |
| 4 | 2.883-083.0 | Spare part set | |
| 5 | 6.472-113.0 | Filter cartridge | |
| 6 | 6.472-123.0 | Filter housing complete | |
| 7 | 5.668-001.0 | Spark holder | |
| 7 | 6.472-122.0 | Protecting cap | |
| 8 | 7.303-033.0 | Screw M4x16-ST-A2R (KOMBI-IN6RD | |
| 8 | 7.311-037.0 | Hexagon nut M 5-CU2 ISO 4032 | |
| 8 | 6.472-109.0 | Housing spring | |
| 9 | 5.841-298.0 | Control panel | |
| 9 | 5.667-042.0 | Nozzle holder | |
| 10 | 5.332-028.0 | Helical spring | |
| 10 | 6.472-108.0 | Pin | |
| 10 | 6.415-001.0 | Nozzle 1,35 60G H | |
| 11 | 5.581-178.0 | Valve seat | |
| 11 | 7.306-443.0 | Винт с цилиндрической головкой М4х12 | |
| 12 | 6.362-712.0 | O-Ring seal 25,3 X 2,4 | |
| 12 | 6.472-128.0 | Diaphragm | |
| 12 | 7.303-136.0 | Sheet metal screw ST3,5X 6,5-ST-R2R (IN | |
| 13 | 6.362-386.0 | O-Ring seal 5,0 x 1,5-NBR 80 | |
| 13 | 5.000-590.0 | Plate | |
| 14 | 5.587-054.0 | Valve housing | |
| 14 | 6.472-340.0 | Knurled nut | |
| 14 | 5.364-100.0 | Flat gasket | |
| 15 | 6.388-515.0 | Hose clip | |
| 15 | 6.278-014.0 | Glass pane | |
| 16 | 6.388-559.0 | Hose clip | |
| 16 | 7.311-380.0 | Cap nut M6 -6-A2E DIN 1587 | |
| 17 | 6.472-125.0 | O-Ring seal 12,0 X 1,5 | |
| 17 | 6.388-194.0 | Hose DN 7 | |
| 17 | 7.312-167.0 | Toothed lock washer A6,4-FSt-A3E DIN 67 | |
| 18 | 6.472-411.0 | Solenoid valve | |
| 18 | 6.388-225.0 | Hose DN 7 | |
| 18 | 4.654-091.0 | Cover D.K. | |
| 19 | 6.472-120.0 | O-Ring seal 28,5 X 1,6 | |
| 19 | 6.414-028.0 | Filter | |
| 19 | 7.311-003.0 | Hexagon nut M6 -8-A2E ISO 4032 | |
| 20 | 6.651-316.0 | Lens housing red | |
| 21 | 4.663-060.0 | Burner cage | |
| 22 | 6.472-105.0 | Seal axle | |
| 44 | 7.311-002.0 | Hexagon nut M5 -8-A2E ISO 4032 |
