| REF. | АРТИКУЛ | ОПИСАНИЕ | ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
|---|---|---|---|
| 0 | 3.593-060.0 | Float valve | |
| 1 | 5.585-004.0 | Float | |
| 1 | 6.815-019.0 | Tool - extractor blower wheel 22x10mm | |
| 1 | 6.389-768.0 | Hose clip | |
| 1 | 4.066-230.0 | Cover complete | |
| 2 | 6.362-571.0 | O-Ring seal complete /1ST.-R | |
| 2 | 7.311-422.0 | Hexagon nut M 6-1.4305 ISO 10511 | |
| 2 | 6.389-534.0 | Hose | |
| 2 | 5.031-372.0 | Flap | |
| 3 | 5.107-097.0 | Bar | |
| 3 | 7.312-279.0 | Washer 6-CuZn ISO 7093-1 | |
| 3 | 6.389-262.0 | Union nut A 4-LL | |
| 3 | 7.303-096.0 | Screw 4x22 -ST-10.9-R2R (IN6RD) | |
| 4 | 6.362-664.0 | O-Ring seal 1,1 X 1,78 -NBR 90 | |
| 4 | 5.115-158.0 | Washer | |
| 4 | 6.389-263.0 | Cutting ring d.4 | |
| 4 | 5.063-723.0 | Cover | |
| 5 | 5.581-244.0 | Valve seat | |
| 5 | 7.306-194.0 | Screw M6x20 -A2-70 (In6Rd) | |
| 5 | 6.389-261.0 | Screw union | |
| 5 | 5.066-862.0 | Cover | |
| 6 | 5.582-089.0 | Valve disc | |
| 6 | 7.316-004.0 | Bolt A 3x25 -CuZn ISO 2340 | |
| 7 | 5.332-254.0 | Helical spring | |
| 7 | 5.481-029.0 | Lever | |
| 7 | 6.362-855.0 | O-Ring seal 56,0 X 4,0 | |
| 8 | 5.115-444.0 | Washer | |
| 8 | 5.394-066.0 | Protection part | |
| 8 | 4.421-234.0 | Pipelines | |
| 8 | 7.303-045.0 | Screw M5X 55-ST-A2R (IN6RD) | |
| 9 | 6.362-467.0 | O-Ring seal complete 1ST.-R. | |
| 9 | 5.584-026.0 | Valve pin | |
| 9 | 6.631-081.0 | Switch | |
| 10 | 6.362-673.0 | O-Ring seal 14,0 X 1,78 | |
| 10 | 5.364-095.0 | Flat gasket | |
| 10 | 6.472-927.0 | Hose stem only for replacement | |
| 10 | 7.306-058.0 | Screw M 4X 12- 8.8-R2R K-IN6RD | |
| 11 | 5.411-080.0 | Screw plug | |
| 11 | 5.587-103.0 | Valve housing | |
| 12 | 6.362-161.0 | O-Ring seal 19,3 X 2,4 | |
| 12 | 6.362-598.0 | O-Ring seal 13,94X 2,62 | |
| 13 | 5.115-527.0 | Washer | |
| 13 | 5.443-224.0 | Hose stem | |
| 14 | 5.321-405.0 | Handhold sleeve | |
| 14 | 5.310-061.0 | """Nut R 3/4"""" """ | |
| 15 | 6.362-522.0 | O-Ring seal 24,0 X 2,0 | |
| 15 | 6.388-547.0 | Hose clip | |
| 16 | 5.384-013.0 | Inspection glass | |
| 16 | 5.442-894.0 | Hose DN16 | |
| 17 | 5.060-439.0 | Housing | |
| 17 | 7.316-432.0 | Cotter 4x50 -St-A2E ISO 1234 | |
| 18 | 7.343-482.0 | Snap ring A24-1.4310 DIN 7993 | |
| 18 | 5.070-076.0 | Tank | |
| 19 | 6.362-559.0 | O-Ring seal 18,77X 1,78 | |
| 19 | 7.303-042.0 | Screw M5x25 -St-R2R (In6Rd) | |
| 20 | 6.362-428.0 | O-Ring seal 26,0 X 1,5 -NBR 70 | |
| 20 | 7.312-002.0 | Washer 5-200HV-A3E ISO 7090 | |
| 24 | 6.389-886.0 | Hose 19X4 | |
| 25 | 6.388-548.0 | Hose clip | |
| 26 | 5.310-062.0 | Nut | |
| 27 | 5.443-211.0 | Hose stem | |
| 29 | 6.310-082.0 | Putting nut M6 | |
| 30 | 7.306-089.0 | Screw M6x12 -8.8-R2R (In6Rd) | |
| 33 | 5.363-545.0 | Seal | |
| 35 | 5.363-336.0 | Seal | |
| 36 | 5.731-587.0 | Water filter | |
| 37 | 4.730-127.0 | Water filter | |
| 45 | 4.053-101.0 | Bracket | |
| 46 | 7.312-004.0 | Washer 8 -200HV-A3E ISO 7090 | |
| 47 | 6.303-031.0 | Screw M8x16-ST-A2R DIN 7500-1 | |
| 48 | 5.063-226.0 | Cover | |
| 49 | 5.332-001.0 | Helical spring | |
| 50 | 4.070-196.0 | Tank | |
| 51 | 6.362-113.0 | O-Ring seal 6,0 x 2,0 NBR 70 | |
| 52 | 6.686-143.0 | Solenoid valve DN3 |
