Karcher (Керхер) Pучной пистолет-распылитель (0.148-979.0)
Не нашли подходящую запчасть? Позвоните +7 (843) 503-04-85
| REF. |
АРТИКУЛ |
ОПИСАНИЕ |
ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
| 0 |
4.775-080.0 |
Hand trigger gun replacement |
|
| 1 |
4.775-555.0 |
Hand trigger gun replacement 35 Mpa |
|
| 1 |
6.631-190.0 |
Motor protecting switch |
|
| 1 |
6.631-428.0 |
Motor protecting switch -22-27A |
|
| 1 |
6.491-251.0 |
Cap of a tank |
|
| 1 |
5.304-063.0 |
Hexagonal head screw |
|
| 1 |
7.303-096.0 |
Screw 4x22 -ST-10.9-R2R (IN6RD) |
|
| 2 |
7.303-096.0 |
Screw 4x22 -ST-10.9-R2R (IN6RD) |
|
| 2 |
7.309-016.0 |
Screw M4x22-Z7-1 -4.8-A2E DIN6900 |
|
| 2 |
6.491-289.0 |
Wing nut |
|
| 2 |
6.362-468.0 |
O-Ring seal complete 1ST.-R. |
|
| 2 |
5.321-230.0 |
Handhold few |
|
| 3 |
5.481-331.0 |
Slider |
|
| 3 |
6.641-708.0 |
Clamping washer 5 |
|
| 3 |
6.491-290.0 |
Cover air filter |
|
| 3 |
5.411-092.0 |
Screw plug |
|
| 3 |
4.481-050.0 |
Lever |
|
| 4 |
7.303-039.0 |
Screw M5x16 -St-A2R (In6Rd) |
|
| 4 |
6.491-291.0 |
Nut -VANGUARD V-TWIN |
|
| 4 |
6.362-412.0 |
O-Ring seal 22x1,5-NBR 70 |
|
| 4 |
5.481-052.0 |
Lever |
|
| 5 |
6.472-112.0 |
O-Ring seal 10,0 x 2,4 NBR 70 |
|
| 5 |
6.491-292.0 |
Cover plate -VANGUARD V-TWIN |
|
| 5 |
6.362-175.0 |
O-Ring seal 5,28x 1,78 |
|
| 5 |
5.411-067.0 |
Screw plug |
|
| 6 |
5.321-802.0 |
Handhold few |
|
| 6 |
5.321-556.0 |
Handhold |
|
| 6 |
6.491-213.0 |
Air filter insert |
|
| 6 |
7.311-218.0 |
Hexagon nut M 6-LH-CU2 ISO 4035 |
|
| 6 |
5.332-157.0 |
Helical spring |
|
| 7 |
4.037-013.0 |
Hook |
|
| 7 |
6.313-003.0 |
Locking spring |
|
| 7 |
6.491-293.0 |
Prefilter -VANGUARD V-TWIN |
|
| 7 |
7.311-004.0 |
Hexagon nut M8 -8-A3E ISO 4032 |
|
| 7 |
5.582-084.0 |
Valve disc |
|
| 8 |
5.110-596.0 |
Sleeve |
|
| 8 |
5.066-615.0 |
Cover |
|
| 8 |
6.491-260.0 |
Handhold for pull cord |
|
| 8 |
6.362-610.0 |
O-Ring seal complete 2ST.-R. |
|
| 8 |
6.362-584.0 |
O-Ring seal 12,42X 1,78 |
|
| 9 |
4.363-691.0 |
O-Ring seal kpl. -nur fuer Ersatz- |
|
| 9 |
6.273-070.0 |
Seal string cellular rubber 4 |
|
| 9 |
6.491-294.0 |
Starter rope |
|
| 9 |
5.553-252.0 |
Piston |
|
| 9 |
7.307-417.0 |
Threaded pin M8x16 -45H-A2E ISO 4026 |
|
| 10 |
6.390-208.0 |
Hose assembly DN8 40MPa 20m |
|
| 10 |
7.303-501.0 |
Self-tapping screw M3x20-ST-A2E DIN 7500 |
|
| 10 |
6.491-296.0 |
Spark plug connector |
|
| 10 |
5.332-229.0 |
Пружина |
|
| 10 |
5.107-097.0 |
Bar |
|
| 11 |
6.643-151.0 |
Strip terminal one-pole 16mm? |
|
| 11 |
6.491-250.0 |
Ignition plug |
|
| 11 |
6.362-480.0 |
O-Ring seal 12,42x 1,78 |
|
| 11 |
6.362-571.0 |
O-Ring seal complete /1ST.-R |
|
| 12 |
6.647-408.0 |
Twisting sleeve PG13,5 |
|
| 12 |
6.641-343.0 |
Cable gland PG13,5 |
|
| 12 |
5.581-148.0 |
Valve seat |
|
| 12 |
4.427-131.0 |
Manifold |
|
| 13 |
6.641-394.0 |
Adaptor PG13,5-PG16 |
|
| 13 |
6.491-285.0 |
Oil filter cartridge |
|
| 13 |
5.584-078.0 |
Valve pin |
|
| 14 |
6.641-356.0 |
Cable gland PG16 |
|
| 14 |
6.491-176.0 |
Parallel key 6,3X36 |
|
| 14 |
4.550-098.0 |
Cylinder head complete |
|
| 15 |
6.491-295.0 |
Seal exhaust |
|
| 15 |
6.313-003.0 |
Locking spring |
|
| 16 |
5.321-198.0 |
Handhold |
|
| 19 |
6.491-220.0 |
Filter gasoline |
|
| 20 |
6.491-298.0 |
Screw exhaust |
|
| 21 |
6.491-299.0 |
Switch oil pressure |
|
| 22 |
6.288-050.0 |
Engine oil 1L |
|
| 23 |
6.491-368.0 |
Control device |
|
| 24 |
6.388-278.0 |
Hose DN10 |
|
| 26 |
6.491-329.0 |
Key switch |
|
| 27 |
6.491-307.0 |
Ignition key |
|
