| REF. | АРТИКУЛ | ОПИСАНИЕ | ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
|---|---|---|---|
| 1 | 5.321-107.0 | Handhold few | |
| 1 | 5.063-274.0 | Cover | |
| 2 | 7.303-096.0 | Screw 4x22 -ST-10.9-R2R (IN6RD) | |
| 2 | 7.303-084.0 | Screw 4x25 -10.9-R2R (K-In6Rd) | |
| 3 | 6.362-176.0 | O-Ring seal 6,07x1,78 | |
| 3 | 5.600-021.0 | Impeller | |
| 4 | 5.322-006.0 | Hand wheel | |
| 4 | 6.343-166.0 | Tolerance ring D14X8 | |
| 5 | 5.030-283.0 | Moulded part | |
| 5 | 5.100-096.0 | Shaft | |
| 6 | 5.553-118.0 | Piston | |
| 6 | 7.401-115.0 | Ball bearing 6002-2RS -WAELZLAGST DIN 62 | |
| 7 | 6.362-477.0 | O-Ring seal complete 1ST.-R. | |
| 7 | 6.343-031.0 | Tolerance ring 15X12 | |
| 8 | 5.107-062.0 | Bar | |
| 8 | 5.625-225.0 | Belt pulley | |
| 9 | 5.115-227.0 | Washer | |
| 9 | 6.388-608.0 | Tightening strap | |
| 10 | 5.305-110.0 | Shaped screw | |
| 10 | 5.178-025.0 | Cloth collar | |
| 11 | 6.362-468.0 | O-Ring seal complete 1ST.-R. | |
| 11 | 6.303-320.0 | Screw M 5x 20-St-R2R | |
| 12 | 5.115-260.0 | Washer | |
| 12 | 7.312-264.0 | Washer 5-100HV-A3E ISO 7094 | |
| 13 | 6.362-478.0 | O-Ring seal 12,42X 1,78 | |
| 13 | 5.110-306.0 | Sleeve | |
| 14 | 5.332-140.0 | Helical spring | |
| 14 | 5.379-011.0 | Rubber ring | |
| 15 | 4.581-013.0 | Valve seat | |
| 15 | 6.472-363.0 | Coupler | |
| 16 | 5.110-240.0 | Sleeve 800L/H | |
| 16 | 6.472-377.0 | Coupling element | |
| 17 | 6.362-479.0 | O-Ring seal 7,59X 2,62 | |
| 17 | 7.303-077.0 | Sheet metal screw ST4,8X16-ST-A2R (IN6R | |
| 18 | 5.427-079.0 | Manifold | |
| 18 | 7.312-278.0 | Washer 5-200HV-A2E ISO7093-1 | |
| 19 | 6.362-496.0 | O-Ring seal 17,12X 2,62-NBR 70 | |
| 19 | 5.606-002.0 | Air flap | |
| 20 | 6.303-058.0 | Oval head screw 2,9X 13-ST-VERZ | |
| 20 | 5.605-143.0 | Housing | |
| 21 | 5.040-480.0 | Sheet metal component | |
| 22 | 5.335-013.0 | Spiral spring | |
| 23 | 5.325-010.0 | Lever | |
| 24 | 5.325-009.0 | Lever | |
| 25 | 6.303-025.0 | Oval head screw 4,2x16-St-vz | |
| 26 | 7.312-001.0 | Washer 4 -200HV-A3E ISO 7089 | |
| 27 | 5.030-321.0 | Moulded part | |
| 28 | 5.040-479.0 | Sheet metal component | |
| 29 | 6.390-010.0 | Hose assembly rotatable DN8 max.31,5MPa |
