| REF. | АРТИКУЛ | ОПИСАНИЕ | ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
|---|---|---|---|
| 2 | 5.321-332.0 | Handhold few | |
| 3 | 7.306-133.0 | Screw M6x50 -8.8-R3R (In6Rd) | |
| 4 | 7.311-003.0 | Hexagon nut M6 -8-A2E ISO 4032 | |
| 5 | 6.304-099.0 | Saucer-head screw M 6x 18-4.8-R2R | |
| 6 | 5.332-157.0 | Helical spring | |
| 6 | 4.580-238.0 | Proportioning valve chemistry | |
| 7 | 5.582-058.0 | Valve disc | |
| 8 | 6.362-584.0 | O-Ring seal 12,42X 1,78 | |
| 9 | 6.362-113.0 | O-Ring seal 6,0 x 2,0 NBR 70 | |
| 9 | 7.307-417.0 | Threaded pin M8x16 -45H-A2E ISO 4026 | |
| 10 | 5.443-442.0 | Nipple | |
| 10 | 5.107-259.0 | Bar | |
| 10 | 5.071-069.0 | Tank | |
| 11 | 6.362-571.0 | O-Ring seal complete /1ST.-R | |
| 12 | 6.362-381.0 | O-Ring seal 13x2 - NBR 70 | |
| 12 | 4.427-179.0 | Manifold | |
| 12 | 5.023-117.0 | U-Section | |
| 13 | 4.580-323.0 | Valve complete | |
| 13 | 5.031-259.0 | Moulded part | |
| 14 | 6.303-025.0 | Oval head screw 4,2x16-St-vz | |
| 14 | 6.343-170.0 | Retaining clip | |
| 15 | 5.321-524.0 | Handhold few neutrally | |
| 16 | 6.303-174.0 | Screw 6,0X20-ST-A2R | |
| 17 | 6.391-420.0 | High pressure hose neutrally DN 6 | |
| 18 | 5.605-226.0 | Housing | |
| 19 | 6.363-115.0 | O-Ring seal complete 1ST.-R. | |
| 20 | 5.028-561.0 | Tube | |
| 22 | 6.343-162.0 | Lock washer -25 | |
| 27 | 5.332-203.0 | Helical spring | |
| 29 | 5.411-070.0 | Screw plug | |
| 30 | 5.110-608.0 | Sleeve | |
| 31 | 6.362-175.0 | O-Ring seal 5,28x 1,78 | |
| 36 | 6.365-354.0 | Grooved ring 16X24X5,3 | |
| 37 | 6.362-384.0 | O-Ring seal 9x1,5 - NBR 70 |
