| REF. | АРТИКУЛ | ОПИСАНИЕ | ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
|---|---|---|---|
| 1 | 5.321-419.0 | Захватная пара | |
| 2 | 5.066-500.0 | Cover bottom part | |
| 3 | 5.481-082.0 | Lever black | |
| 4 | 5.057-054.0 | Support | |
| 5 | 5.411-054.0 | Screw plug | |
| 6 | 6.362-480.0 | O-Ring seal 12,42x 1,78 | |
| 6 | 5.110-453.0 | Sleeve | |
| 7 | 6.303-153.0 | Screw M5x15-ST-R2R (IN6RD) | |
| 9 | 7.303-031.0 | Screw M4x10 -St-P2R (In6Rd) | |
| 12 | 7.306-090.0 | Screw M6x16 -8.8-R3R (In6Rd) | |
| 13 | 5.110-477.0 | Sleeve | |
| 14 | 6.273-118.0 | Profile gasket cellular rubber | |
| 15 | 6.362-398.0 | O-Ring seal 27,5 X 1,5-NBR 70 | |
| 15 | 6.661-298.0 | Capacitor 40µf | |
| 16 | 7.312-002.0 | Washer 5-200HV-A3E ISO 7090 | |
| 17 | 6.365-354.0 | Grooved ring 16X24X5,3 | |
| 17 | 6.303-149.0 | Oval head screw 5,0X40 | |
| 17 | 6.363-115.0 | O-Ring seal complete 1ST.-R. | |
| 20 | 6.391-420.0 | High pressure hose neutrally DN 6 |
