Karcher (Керхер) Принадлежности (0.147-592.0)
Не нашли подходящую запчасть? Позвоните +7 (843) 503-04-85
| REF. |
АРТИКУЛ |
ОПИСАНИЕ |
ЗАПРОС НАЛИЧИЯ / ЦЕНЫ |
| 0 |
4.623-210.0 |
Motor complete |
|
| 1 |
7.303-096.0 |
Screw 4x22 -ST-10.9-R2R (IN6RD) |
|
| 1 |
7.306-041.0 |
Cylinder head screw M8x20 -8.8-A2E ISO |
|
| 2 |
5.321-107.0 |
Handhold few |
|
| 2 |
7.312-159.0 |
Toothed lock washer A8,4-FST-PH DIN 679 |
|
| 3 |
5.332-140.0 |
Helical spring |
|
| 3 |
5.115-565.0 |
Washer |
|
| 4 |
7.311-003.0 |
Hexagon nut M6 -8-A2E ISO 4032 |
|
| 4 |
6.362-478.0 |
O-Ring seal 12,42X 1,78 |
|
| 4 |
7.318-035.0 |
Parallel key 8x7x25 -C45R DIN 6885-1 |
|
| 5 |
6.304-099.0 |
Saucer-head screw M 6x 18-4.8-R2R |
|
| 5 |
5.115-260.0 |
Washer |
|
| 5 |
5.120-245.0 |
Wobble plate |
|
| 6 |
4.580-238.0 |
Proportioning valve chemistry |
|
| 6 |
6.362-468.0 |
O-Ring seal complete 1ST.-R. |
|
| 6 |
6.401-225.0 |
Taper roller bearing 41 |
|
| 7 |
6.388-194.0 |
Hose DN 7 |
|
| 7 |
5.305-110.0 |
Shaped screw |
|
| 7 |
7.367-005.0 |
Radial shaft seal ring A35x53x7-NBR DIN |
|
| 7 |
7.367-009.0 |
Radial shaft seal ring A35x52x7-NBR DIN |
|
| 8 |
5.025-747.0 |
Tube |
|
| 8 |
5.325-009.0 |
Lever |
|
| 8 |
5.411-100.0 |
Screw plug |
|
| 9 |
6.414-136.0 |
Filter |
|
| 9 |
5.030-283.0 |
Moulded part |
|
| 9 |
6.363-273.0 |
O-Ring seal 11,0 x 2,0 |
|
| 10 |
5.071-069.0 |
Tank |
|
| 10 |
5.322-006.0 |
Hand wheel |
|
| 10 |
6.362-161.0 |
O-Ring seal 19,3 X 2,4 |
|
| 11 |
6.310-062.0 |
Cap nut M 8 |
|
| 11 |
6.362-176.0 |
O-Ring seal 6,07x1,78 |
|
| 11 |
5.070-457.0 |
Tank oil |
|
| 12 |
5.023-117.0 |
U-Section |
|
| 12 |
5.115-227.0 |
Washer |
|
| 12 |
5.063-195.0 |
Cover |
|
| 13 |
7.309-015.0 |
Screw assembly M8x16-8.8-A2E-S4-N ISO106 |
|
| 13 |
5.107-062.0 |
Bar |
|
| 13 |
5.057-055.0 |
Support |
|
| 14 |
6.343-170.0 |
Retaining clip |
|
| 14 |
6.362-477.0 |
O-Ring seal complete 1ST.-R. |
|
| 14 |
6.288-016.0 |
Gear oil 1L |
|
| 15 |
6.647-400.0 |
Cable complete |
|
| 15 |
6.647-379.0 |
Cable with plug |
|
| 16 |
6.303-174.0 |
Screw 6,0X20-ST-A2R |
|
| 16 |
6.303-058.0 |
Oval head screw 2,9X 13-ST-VERZ |
|
| 17 |
5.004-641.0 |
Strap |
|
| 17 |
5.040-480.0 |
Sheet metal component |
|
| 18 |
5.605-226.0 |
Housing |
|
| 18 |
5.335-013.0 |
Spiral spring |
|
| 19 |
6.310-053.0 |
Putting nut |
|
| 19 |
5.325-010.0 |
Lever |
|
| 20 |
5.553-118.0 |
Piston |
|
| 20 |
5.028-561.0 |
Tube |
|
| 20 |
5.030-321.0 |
Moulded part |
|
| 21 |
6.303-025.0 |
Oval head screw 4,2x16-St-vz |
|
| 21 |
7.312-060.0 |
Washer 24-100HV-A3E ISO 7091 |
|
| 21 |
7.312-001.0 |
Washer 4 -200HV-A3E ISO 7089 |
|
| 22 |
7.312-001.0 |
Washer 4 -200HV-A3E ISO 7089 |
|
| 22 |
6.343-162.0 |
Lock washer -25 |
|
| 23 |
5.030-321.0 |
Moulded part |
|
| 23 |
6.435-236.0 |
Wheel D.250 |
|
| 24 |
5.335-013.0 |
Spiral spring |
|
| 24 |
4.581-013.0 |
Valve seat |
|
| 24 |
6.435-237.0 |
Wheel cap |
|
| 25 |
5.040-480.0 |
Sheet metal component |
|
| 25 |
5.110-239.0 |
Sleeve 155-280L/H |
|
| 25 |
5.057-054.0 |
Support |
|
| 26 |
6.303-058.0 |
Oval head screw 2,9X 13-ST-VERZ |
|
| 26 |
6.362-479.0 |
O-Ring seal 7,59X 2,62 |
|
| 26 |
5.028-703.0 |
Tube |
|
| 27 |
5.040-479.0 |
Sheet metal component |
|
| 27 |
5.427-079.0 |
Manifold |
|
| 27 |
5.321-430.0 |
Handhold |
|
| 28 |
5.325-010.0 |
Lever |
|
| 28 |
6.362-496.0 |
O-Ring seal 17,12X 2,62-NBR 70 |
|
| 28 |
5.337-021.0 |
Plate spring |
|
| 30 |
6.391-342.0 |
High pressure hose only for replacement |
|
| 30 |
6.389-567.0 |
Hose clip |
|
| 31 |
5.040-479.0 |
Sheet metal component |
|
| 32 |
4.760-660.0 |
Jet pipe packaged only for replacement |
|
| 33 |
6.303-025.0 |
Oval head screw 4,2x16-St-vz |
|
| 34 |
5.321-150.0 |
HANDLE (PART NO=ONE HALF) |
|
| 35 |
6.362-529.0 |
Joint ring 12x1,5 |
|
| 36 |
7.401-921.0 |
Sphere 4 G20 -1.4034 DIN 5401 |
|
| 37 |
6.362-524.0 |
O-Ring seal 17,0 X 1,5 |
|
| 38 |
4.363-692.0 |
Grooved ring kpl. -nur fuer Ersatz- |
|
| 39 |
6.362-469.0 |
O-Ring seal 21,95X 1,78 |
|
| 40 |
5.765-023.0 |
Nozzle 065 |
|
| 41 |
6.362-578.0 |
O-Ring seal 6,0 X 1,0-NBR 85 |
|
| 43 |
5.394-213.0 |
Protection part |
|
| 45 |
7.401-910.0 |
Sphere 3/8 G80-1.4034 DIN 5401 |
|
| 46 |
5.734-068.0 |
Strainer |
|
| 47 |
4.402-039.0 |
Screw union |
|
